EMOTRON
CG Drives & Automation presents a new range of variable frequency drives (VFDs) for 160-4000kW, 230-690V within the Emotron brand. The range includes many new frame sizes for high power drives. .
Variable Frequency Drives
Efficient and protective starts and stops
Emotron VFX ensures efficient and protective starts. Reduced start currents result in smaller fuses, cables – and energy bills. Torque can be boosted to overcome initial peak loads. Integrated vector braking ensures quick and controlled stops, increasing not only productivity but safety as well.
Optimised operation and full control
The direct torque control reacts extremely quickly to eliminate disturbances due to abrupt load changes. A built-in load monitor and a unique Load Curve Protection function protect your process by immediately detecting any situation that could cause inefficiency or damage. Early warnings and safety stops for over- and underloads allow preventive action.
User-friendly and reliable operation
Operation parameters can be set in your own process units – m/sec, tons/hour, cycles/min etc. – making monitoring easier and more reliable. The removable control panel has a copy function for transferring settings to other Emotron VFX units. You can switch between local and remote control by the push of a button on the control panel. The built- in programmable logical functions, comparators and timers mean that, in many cases, external PLC or relays can be avoided.
Available in IP20/21 and IP54 versions
Emotron VFX is available in IP20/21and IP54 versions. The robust metal construction in IP54 version allows you to install your AC drive close to the application, which saves the cost of cabinets and long motor cables. The 300-3,000 A units (IP20 modules) are also available in compact CG-designed IP54. IP20/21 series 2.5-365 A are optimised for mounting in control cabinets (IP20) or on electrical room walls (IP21, 25-365A). Emotron VFX has a robust and compact design, with easy access to power terminals and an extended temperature range up to 55 °C
Simplified maintenance
Should a process problem occur, a full status report will be generated. You can quickly identify the cause and take corrective measures. Maintenance is simplified thanks to a minimum of easy accessible mechanical parts and fold-out power modules.
Technical Data
EMOTRON VFX IP54 version
Rated power 0.75-4,000 kW
Supply voltage 230-690 V, 3-phase
Rated current 2.5-4,000 A
Protection class IP54
Approvals CE, UL/cUL (400V), DNV, EAC
EMOTRON VFX IP20/21 version
Rated power 11-1,600kW/400V, 1.5-55kW + 250-4,000kW/690V
Supply voltage 230-690V, 3-phase
Rated current 25-2920A/400V, 2-58A + 250-4,000A/690V
Protection class IP20 (optional 21)
Approvals CE, UL/cUL (400V), EAC
